TP-UBC-5.0T
TOPLIFT
| Quantity: | |
|---|---|
Model No: UBC
Globally Tried and Tested
The UBC Universal Beam Clamp is a strong and dependable lifting device, built for both vertical and side load handling—especially where standard clamps fall short. Tested globally under tough conditions, it offers exceptional strength and flexibility, making it suitable for lifting, pulling, and semi-permanent anchoring.
Capable of multi-directional loading, it supports lifting from any angle, reducing the need for spreader beams and simplifying rigging. A newly added 10-ton deep flange model (up to 40mm) increases beam compatibility.
Full technical documentation is provided to ensure safe, effective use.
⚠️ Caution: Do not exceed the rated load limit. Not intended for lifting flat plates.
Rated for full capacity at all angles
Load options: 3.0t, 5.0t, 10.0t
Deep flange compatibility (up to 40mm)
Fast and flexible rigging point
Low headroom profile for tight spaces
Suitable for lifting, pulling, or anchoring
Supports vertical and side loading
Fits various beam widths
Threaded spindle offers firm grip
Operates in temperatures from -40°C to +80°C (extendable to -60°C)
Safety Factor:
5:1 for straight lifts
4:1 for angular lifts
Our advantages
OEM services available
Competitive pricing for premium quality
10+ years of experience in lifting equipment manufacturing
Specification
| Product Code | Capacity /T | Dimension/mm | Net Weight /KG | ||||||||||
| A | B | C | D | E | F | G | H | J | K | L | |||
| TP-UBC-3T | 3.0 | 565 | 60 | 70 | 70 | 32 | 232 | 102 | 20 | 32 | 20 | 125-240 | 15 |
| TP-UBC-5T | 5.0 | 645 | 70 | 84 | 80 | 32 | 270 | 120 | 23 | 38 | 25 | 125-305 | 24 |
| TP-UBC-10T | 10.0 | 645 | 70 | 88 | 80 | 32 | 270 | 120 | 23 | 38 | 25 | 125-305 | 27 |
Details
The Toplift beam clamp offers a secure, stationary lifting solution without the need for drilling.
Its welded, powder-coated jaws are actuated by a threaded spindle, enabling quick and reliable clamping onto overhead I-beams.
Designed for broad I-beam compatibility, the clamp fits various flange sizes. Once secured, the built-in suspension bar accommodates multiple rigging attachments—an ideal feature for operations in low-clearance spaces.
Application
TP-UBC clamp can be applied in these situations, such as warehouse storage, construction operation, port wharf, steel plate transportation and so on.
