TP-UBC-10.0T
TOPLIFT
| Quantity: | |
|---|---|
Model No: UBC
Globally Tried and Tested
The UBC Universal Beam Clamp is your go-to solution for heavy-duty lifting—engineered for precision, performance, and reliability where traditional clamps just can’t keep up. With proven results in demanding global environments, it’s the ideal tool for lifting, pulling, or acting as a fixed anchor point.
This clamp allows full-angle loading, eliminating the need for spreader bars and making setup faster and easier. The latest 10-ton deep flange version (up to 40mm) brings even greater compatibility for broader applications.
Comprehensive documentation is included to ensure you can use it with confidence.
⚠️ Reminder: Stay within the rated load capacity. Not suited for lifting flat metal plates.
Maximum load capacity from any angle
Models in 3.0t, 5.0t, and 10.0t
Deep flange support up to 40mm
Quick connection point for hoists and gear
Compact design for low-clearance environments
Multipurpose: lift, pull, or anchor
Safe for vertical and side loads
Broad beam width compatibility
Secure clamping with multi-directional spindle
Reliable performance from -40°C to +80°C (optional to -60°C)
Safety Factor:
5:1 for straight lifts
4:1 for angular lifts
Our advantages
OEM manufacturing tailored to your brand
Excellent value without compromising quality
A decade of industry experience and know-how
Specification
| Product Code | Capacity /T | Dimension/mm | Net Weight /KG | ||||||||||
| A | B | C | D | E | F | G | H | J | K | L | |||
| TP-UBC-3T | 3.0 | 565 | 60 | 70 | 70 | 32 | 232 | 102 | 20 | 32 | 20 | 125-240 | 15 |
| TP-UBC-5T | 5.0 | 645 | 70 | 84 | 80 | 32 | 270 | 120 | 23 | 38 | 25 | 125-305 | 24 |
| TP-UBC-10T | 10.0 | 645 | 70 | 88 | 80 | 32 | 270 | 120 | 23 | 38 | 25 | 125-305 | 27 |
Details
The Toplift Lifting Beam Clamp is a premium, hassle-free tool for lifting and suspending from overhead I-beams—no drilling required.
Its rugged jaws, coated for durability and operated by a threaded spindle, deliver strong and precise grip every time.
Engineered to fit a wide range of I-beam sizes, this clamp locks securely in place. The integrated suspension bar supports various attachments, making it especially well-suited for low-headroom environments where space is limited.
Application
TP-UBC clamp can be applied in these situations, such as warehouse storage, construction operation, port wharf, steel plate transportation and so on.
