TP-HSH
| Quantity: | |
|---|---|
TP-HSH Portable Lifting Lever Hoist 0.25T -1.5T with high quality
Features
1. Capacity from 0.25T to 1.5T.
2. Bearings inside load chain sprocket increase mechanical efficiency
3. Chain guides provide smooth chain operation.
4. lightweight steel construction with durable powder coat finish.
5. Drop forged hooks and hook holders, heat treated to ensure the safety and durability.
6. Gear assembly provide smooth operation by little hand efforts.
7. T80 grade high tensile lifting chain make more effective.
8. CE CERTIFIED.
Our advantages
1. OEM accepted and offer confidentiality agreement business secret.
2. The same quality product with the best price.
3. We are specialized in the field of lifting equipment and rigging product supply for around 10 years, with rich experience in Production.
Specification
| Model | Rated Load (T) | Test Load (T) | Standard Lift (m) | Min. distance between two hooks (mm) | Efforts required at capacity (N) | No. of Load Chains | Dia. of Load Chain (mm) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | N.W.(kg) |
| HSH-V2.5 | 0.25 | 0.375 | 1 | 205 | 217 | 1 | 4 | 92 | 75 | 205 | 153 | 17 | 1.85 |
| HSH-V5 | 0.5 | 0.75 | 1.5 | 260 | 303 | 1 | 5 | 110 | 82 | 260 | 261 | 23 | 4.6 |
| HSH-V7.5 | 0.75 | 1.125 | 1.5 | 295 | 140 | 1 | 6 | 152 | 128 | 295 | 256 | 26 | 7.7 |
| HSH-V10 | 1 | 1.5 | 1.5 | 295 | 185 | 1 | 6 | 152 | 128 | 295 | 256 | 26 | 8 |
| HSH-V15 | 1.5 | 2.25 | 1.5 | 335 | 234 | 1 | 7.1 | 175 | 148 | 335 | 368 | 30 | 10.6 |
High Standard for Details
The lever block with high quality parts, includes double brakes, precise gear, G80 chain and high quality hook.
Real Shoot of Parts
The picture shows the real shoot of parts: forged shell, high-strength gear and other precise parts.
Packaging
The lever block is packed with carton box, wooden case or customized package.
Product Test Equipment
Before the product leaves the factory, it will pass strict testing.
Factory Environment
We strictly control every step in order to bring the best products to our customers.
FAQ
1.How about after-sales service?
We supply free spare parts to replace your hoists. Besides, we can send your the video to guide your engineers.
2.How to ensure the quality?
Before packing, our chain block will be sent to inspection center for checking. And we take detailed pictures for each hoist before packing. You can offer our serial Number and then know the details.
3.How about the spare parts?
We manufactures 60% spare parts in our own factory to ensure high quality, and the other 40% spare parts from our long term supplier. Before stocking in warehouse, we have strict inspection for each part.
4.If it is warranty?
We can provide parts replacement service. 1 years service for electric parts, and 2 years for mechanical parts.
